September 03, 2015

R Basic Examples

Listed below are couple of basic examples working from R Console

Example 1 - Set and get working directory
Example 2 - Read from Data Files

Example 3 - Count row and columns in data

Example 4 - Functions

Example 5 - Plotting



Happy Learning!!!

August 30, 2015

Video Analytics Class 2

My Notes
  • Represent Image as a Matrix
  • Represent Image as a function
  • Point, local operations, histogram equalization, moving average model
  • Cross Correlation g = H X F
  • Gaussian filter (Removes High frequency, blurring, smoothens image)
  • Symmetric Matrix (When you shift rows into columns it would appear the same ( aij = aji, for all indices i and j) example link
Convolution Basics
Programmatic Walkthru - link

Convolution Applications
  • Smoother image
  • Gaussian (Point spread function)
  • Different Kinds of filter (Box, Gaussian filter)

Cross Correlation - Assess how similar are two different functions. Compares position by position.
Correlation Walkthru

From Link

Mathematics concepts to learn
  • Vector Product
  • Eigen Value decomposition
  • First Derivative, Second Derivative
Vertical and horizontal edge detection filters - Sobel, Roberts, Prewitt (Veritical, Horizontal, Diagonal edge detection filters).

Good Read Link
MIT Course Slides link

Related Reads




Happy Learning!!!

August 25, 2015

OpenCV Python Basics

Basic image loading modules

Example #1

import cv2
import numpy as np
from matplotlib import pyplot as plt
#Load Image
source = cv2.imread('D:\images\Benz.png')

Ref - Link

Example #2

#Printing width and height of image
import cv2
import numpy as np
from matplotlib import pyplot as plt

#Load Image
source = cv2.imread('D:\images\Benz.png')
print source.shape

#Output Number of Rows / Columns
rowCount = source.shape[0]
columnCount = source.shape[1]
print rowCount, columnCount

Ref - Link

Example #3
#Drawing Histogram

import cv2
import numpy as np
from matplotlib import pyplot as plt

#Load Image
source = cv2.imread('D:\images\Benz.png')

# Image, Channel
# Channels - grayscale image - [0], RGB - 0,1,2
# Mask - Supplied None as FULL Region Needed
# histSize - Bin Size
# ranges - 0 to 256
hist = cv2.calcHist([source], [0], None, [256], [0,256])
plt.plot(hist)
plt.show()

Happy Learning!!!

August 24, 2015

SettingUp OpenCV and Python

Reference Steps - Link

1. Download and Install python from link. Install with Default Settings
2. Download and Install MatPlot Lib (Link in reference steps are fine)
3. Download and Install OpenCV executable. Extract it to C:\OpenCV location
4. Now All Installations are located in C:\
5. Open Python IDLE from program files. In win7 run-it-as admin to open Program Files ->Python IDLE
6. Copy File from below location
      From - C:\OpenCV\opencv\build\python\2.7\x86\cv2.pyd
      To - C:\Python27\Lib\site-packages
7. Got the Error Link
8. Download and install numpy from link (Link provided 1.7 of numpy is incorrect. You need 1.9.2)
9. Validating installation steps

Happy Learning!!!

August 23, 2015

Video Analytics Concepts

  • Image - Matrix of Intensity Values
  • Each pixel has a byte where you can store information
  • Image can be represented in a matrix
  • Image can be represented as a function
Image Processing Operations
  • Point, Local, Global
  • Point - Take every pixel and perform operation
  • Local - Local Neighbourhood data manipulation. Global is extension of local
Point Operations
  • Image Enhancement - new_Pixel = max-old_Pixel+min
  • Contrast Stretching - Histogram stretching

Options
  • Local - Noise reduction using moving average
  • Weighted sum of neighbours computation
  • Linear Filtering - Cross Correlation, Gaussian Filter
  • Convolution Vs Correlation
Happy Learning!!!

Statistical Programming Notes - Class 1

Basics
  • Probability - Study of randomness and uncertainty
  • Random Experiment - Process whose outcome we cannot say predictably
  • Sample Space - All possible outcomes
  • Event - Subset of Sample Space
  • Probability Value - Expected occurence of outcome
Concept #1
Frequentist View

P(Event) = Number of Times Expected Event Occured / Total Number of Events
P(A) = N(A) / N

Probability P of an uncertain event A, written P(A), is defined by the frequency of that event based on previous observations

More Reads on this topic
Frequentism and Bayesianism: A Practical Introduction

Concept #1.1
Bayesian - Assign based on Intuition

Concept #2 - Conditional Probability
P(E) occurring given that another dependant event has already occurred

P(A/B) = P(A Intersection B) / P(B)

More Read - Link

Bayes Theorem
Three production lines
48% Red - 6% Production Line Defective
31% Blue - 11% Production Line Defective
21% White - 8% Production Line Defective

P(R/D) = P(R Intersection D) / P(D)

P(R) = .48
P(D/R) = 0.06
P(D) = P(D/R)P(R) + P(D/W)P(W) + P(D/B)P(B)

P(R/D) = P(R Intersection D) / P(D)

P(R/D) = P(R Intersection D) / (P(D/R)P(R) + P(D/W)P(W) + P(D/B)P(B))

Concept #5
Independent Events - Independent Events are not affected by previous events

Dependent Events - Taking coloured marbles from a bag: as you take each marble there are less marbles left in the bag, so the probabilities change.

Independent Events - Taking and replacing coloured marbles from a bag: as you take each marble there are same marbles left in the bag, so the probabilities won't change.

R Programming Concepts
  • R - Interpreted language
  • Assignment operator =, <-
  • Vector - Same as Arrays in other languages
  • B <- matric(c(2,4,3,1,5,7) nrow = 3, ncol = 2). matrix(rows, columns)
  • In Matrix - Data Filled in columnar manner
  • matrix columnar, rowwise operations possible using apply command apply(b,2,mean) - Columnar mean, apply(b,1,mean) - rowwise mean
  • Data Frame - Way to store different types of columns, Values in one particular column need to be of same data type
Happy Learning!!!

August 19, 2015

Basics - Excellent Read for Database Enthusiasts

Basics - Excellent Read for Database Enthusiasts - How RDBMS works

Happy Learning!!!

August 17, 2015

Variance and Standard Deviation Example

Basic Example for Variance, Standard Deviation Computation



Happy Learning!!!

R Notes

Matrices
Tip #1
Declaration - matrix (0,3,4)
3 rows, 4 columns and values 0
print[1,1]

Tip #2
Vector a <- 1:12 (To fill Matrix)
matrix(a, 3, 4)

Tip #3

Assigning, Fetching & Printing values
plank <- 1:8 - Create Vector
dim(plank) <- c(2,4) - Assign Dimension
print(plank) - Print values
plank[1,4] <- 0 - Assign value
plank[2,] - Fetch all 2nd row values

Tip #4 - Plotting Matrix

elevation <- matrix(2,5,10)
contour(elevation) - 2D representation
persp(elevation) - 3D representation
persp(elevation, expand = 0.2)

Statistics
Tip #1 - Mean computation
a <- c(1,2,3,4,5)
mean(a)
barplot(a)
median(a)

Tip #2
Horizontal line across plots
abline(h=mean(a))
abline(h=median(a))

Tip #3
Standard Deviation
deviation <- sd(a)

Factors
Tip #1
R has special collection called factors
chests <- c('gold', 'silver', 'gems', 'gold', 'gems')
types <- factor(chests)
print(types)

Data Frame
Similar to Database
Tip #1 - Loading data from files
read.csv("data.csv")
read.table("a.txt",sep="\t")

Tip #2 - Merge Data Frames
data1 <- read.csv("data.csv")
data2 <- read.table("a.txt",sep="\t")
merge(x = data1, y = data2)

Real World Examples
Data1 <- read.csv("a.csv")
Data2 <- read.table("b.txt", sep="  ", header=TRUE)
TargetData <- merge(x = Data1, y = Data2)
plot(TargetData$Data1, TargetData$Data2)

August 16, 2015

R Online Learning


I prefer to switch topics when I find it tricky to focus on one topic. I found R language easy, simple and great to get started. Codeschool has a beautiful self learning portal. This lists cheat sheet and fundamentals working with R. Capturing some of notes for my future reference.

Using R

Tip #1 - Assignment
x <- 42
y <- "Hello"

Tip #2 - Expression
5==10
5>10

Tip #3 - Arithmetic operations
2+2
3*3

Tip #4 - Functions
sum(1,2)
sum(1,2,3,4)

Help

Tip #5 - File I/O
list.files()
source(filename)

Vectors

Tip #1 - Vector
List of Values - vector represented by c(2,3,4)
List of Strings - vector represented by c('a','b','c')
List with multiple data types - vector represented by c(1,'a', TRUE)

Tip #2 - Sequence Vectors
Representing sequence of numbers m to b by m:n
 - seq(10,50)
 - seq(10,50,5) - With increment step 5
 - seq(50,10) - Reverse sequence representation

Tip #3 - Assigning Vectors (Single Quotes)
sentence <- c('walk', 'the', 'plank')
sentence[3]
a <- c (1,2,3)
b <- c (1,2,3)

Sample Vector Operations
a+1
a*2
a+b

x <- seq(1, 20, 0.1)
y <- sin(x)

Tip #4
c for combine vectors
c(1,2,3)

Tip #5
Plotting Vectors
vectorCoordinates <- c(4, 5, 1)
barplot(vectorCoordinates)
barplot(1:100)

x <- seq(1, 20, 0.1)
y <- sin(x)
plot(x,y)

Great Learning Sites
Statsmethod
Code School

Happy Learning!!!

August 15, 2015

Recommendation Algorithm Analysis

Item to Item Rating based on customer’s purchase of products


The formula for comparison is dot product divided by product of vector lengths
In the example for two sets Book and DVD
  • Book – (1,1,1) – Set A consider it as (A1, A2, A3)
  • DVD – (1,0,0) – Set B consider it as (B1, B2, B3)
Formula works as
  • (A1.B1 + A2.B2 + A3.B3) /sqrt((A1 square + A2 Square + A3 Square)( B1 square + B2 Square + B3 Square))
  • (1)/sqrt((3).sqrt(1)
  • 1 / 1.732
  • 0.577
     Item to Item Comparison based on customer ratings

The formula for comparison is dot product divided by product of vector lengths
In the example for two sets Book and DVD
  • Book – (4,3,5) – Set A consider it as (A1, A2, A3)
  • DVD – (1,0,0) – Set B consider it as (B1, B2, B3)
Formula works as
  • (A1.B1 + A2.B2 + A3.B3) /sqrt((A1 square + A2 Square + A3 Square)( B1 square + B2 Square + B3 Square))
  • (4)/sqrt((16+9+25).sqrt(1)
  • 4/7.07
  • 0.565
Analysis - By comparing multiple items the items that yield the maximum value would be recommended to the customer

Happy Learning!!!

August 14, 2015

Good Courses

Bookmarking two useful courses on Statistics and Machine Learning

Machine Learning Coursera

Statistics 110


Statistics and Data



Statistics One


Descriptive Statistics





Happy Learning!!!

Inverse Matrix Computation

Matrix A Represented by




Reference - Link

Happy Learning!!!


August 13, 2015

Matrix and Determinants (Basics)

Back to School and basics. These posts are for my on-line references.

Matrix
  • Rectangular Array of Numbers in rows and columns
  • Example - [5,2,-3]
  • Order of Matrix is represented as Rows X Columns
Types of Matrices
  • Row matrix (1 Row, any number of columns)
  • Column matrix (1 Column, Multiple Rows)
  • Diagonal matrix (Square matrix, Except diagonal elements every other elements are 0)
  • Scalar matrix (Square matrix & Diagonal matrix in which all diagonal elements are same)
  • Identity matrix - Denoted by I - Diagonal Elements are 1 (Square & Diagonal Matrix)
  • Transpose of matrix - Matrix where rows and columns are interchanged
        [ 1, 1, 1 ]
A  = [ 2, 2, 2 ]
        [ 3, 3, 3 ]

Transpose is

A' =   [ 1, 2, 3 ]
          [ 1, 2, 3 ]
         [ 1, 2, 3 ]

Addition of Matrices
  • They should be of same order
  • Add Corresponding elements

A =   [2,3,5]
         [5,7,-2]
        [5,3,0]

B =    [7,-1,5]
          [0,2,3]
         [7,5,2]

Result ( Add Corresponding elements in same positions)

A + B =     [9,2,10]
         [5,9,1]
               [12,8,2]

Subtraction (similar to addition)
  • Order needs to match
A = [7,-2]
       [0,3]

B = [0,2]
[3,5]

A - B = [7,-4]
          [-3,-2]

Scalar Multiplication
  • Multiplying constant with a Matrix
  • Every Element of Matrix Multipled
c = [3,5]
[-2,-10]

-2c =  [-6,-10]
  [4,20]

Matrix Multiplication
  • A (m x n)
  • B (n x p)
  • Columns in a (n) = Number of Rows in B (n)
A = [3,5]
[7,2]
[2,3]

B = [-2,5]
[3,7]

AB = Operate First Row (Operate) Multiple with First Coulmn

A = [3,5] --->
[7,2]
[2,3]

Select Column
B = [-2,5]
[3,7]

  = [ 3 X -2 + 5 X 3,  3 X 5 + 5 X 7 ]
[ 7 X -2 + 2 X 3,  7 X 5 + 2 X 7 ]
[ 2 X -2 + 3 X 3,  2 X 5 + 3 X 7 ]

 = [9,50]
[-8,49]
[5,31]

Matrix Multiplication is not commutative

Determinant of Square Matrix
+  -
A = [5,6]
[3,-4]

|A| = [Multiply Principal Diagonal Elements ] - [Subtract the Next Diagonal Elements]
= (5 X -4) - (3 X 6)
      = -20 - 18
      = -38

Determinant of 3 X 3 Matrix
        +,-,+
A =  [3,-2,1]
       [2,3,4]
       [2,5,4]

= +3 X [3,4] - (-2) X [2,4] + 1 X [2,3]
                  [5,4]               [2,4]           [2,5]

= 3(12-20) + 2 (8-8) + 1(10-6)
       = -24 + 0 + 4
       = -20

References - Link

Happy Learning!!!

June 19, 2015

Mobile Test Automation Startups

Interesting start-ups coming up in this space
Other high visible companies include saucelabs, browserstack, perfecto mobile etc..

Happy Learning!!

June 07, 2015

Weekend Tech Talks

Excellent Talk on Android Testing and Automation Fundamentals



Good Notes / Screenshots from Session

Why Automated Testing, What does it Solve ?


What are pros / cons of Automation vs Manual Test Efforts ?

How to use Record / Play back tools ?

Mobile testing options Emulators / Devices ?

Evaluating a Commercial Tool ?

Happy Learning!!!

June 03, 2015

Setting up Jmeter Code base on Windows

Today Dinesh & myself had a good learning time in setting up Jmeter code base. There are not too many blogs / notes. This is a basic draft capturing the steps at high level. Good one for Windows background developers :).

1. Download Jmeter Zip code from Github
2. Create Project with same name. Eclipse - eclipse-jee-kepler-R-win32-x86_64
3. Setup Java Project

4. Set Ant Perspective

5. Execute Download Jars option as Ant Build (Run as Ant Build)

6. Download all the JAR files from link https://www.bouncycastle.org/latest_releases.html (Below mentioned versions)


Output path specified as below


7. Java Compiler Settings
8. Following code changes done for non matching jars

9. Below value set at Code Level


Happy Learning!!!

May 24, 2015

Interesting Sites

Two new interesting sites

Security Tools and Market Share of them - @ sectoolmarket

Collection of useful tech talks available @ techtalkshub

Happy Learning!!!


April 30, 2015

VodQA Presentation

My VodQA presentation slides


April 19, 2015

Testcomplete - VBScript Notes

Tip #1
Change browser locale setting using registry edit. IE browser locale changes

'Browser language local setting function
Sub SetLanguage_FR()
Set wshShell = CreateObject( "WScript.Shell" )
wshShell.RegDelete "HKEY_CURRENT_USER\Software\Microsoft\Internet Explorer\International\AcceptLanguage"
wshShell.RegWrite "HKEY_CURRENT_USER\Software\Microsoft\Internet Explorer\International\AcceptLanguage", "fr-FR", "REG_SZ"
Set wshShell = Nothing
End Sub

Tip #2
Dictionary object example in VBScript

Sub CreateDictionaryExample()
'Dictionary Adding Values
 set ExpectedValues = CreateObject("Scripting.Dictionary")
   ExpectedValues.add "label17", "User Name:"
   ExpectedValues.add "label23", "Password:"
   ExpectedValues.add "label2", "Please enter Details"
   ExpectedValues.add "Btnlogin", "Submit"
  'Dictionary Listing Values
   nofElemtns = ExpectedValues.Count
   keys = ExpectedValues.Keys()
     for i=0 to nofElemtns-1
        k = keys(i)
        v = ExpectedValues.Item(k)
        Call Log.Message(k & ": " & v)
     next
End Sub

Tip #3 - Disable windows pop up 'Your computer is at Risk' feature.
This link . was useful to fix group policy changes

Tip #4 - Vbscript Kill all browser instances
This stackoverflow code snippet link was useful

Happy Learning!!!
